VA-IPCB2M-SE-36-A-PRO

Model	VA-IPCB2M-CR-36-A-PRO
Imaging Device	1/3″
Effective Pixels Min. Illumination	2MP Color 0.0081ux @ Fl.6(AGC ON) ; B/W O lux @ IR ON
Lens Type/FocaI Length Max. Aperture Ratio	Fixed (m12) / 2.8mm F l.6
Angular Field of View	Horizontal: 97 , Vertical:55 , Diagonal:115
Min. Object Distance	1.5M
IR Viewable Distance	Up to 25m
Day & Night	IR cut filter with auto switch (Day/Night/lmage/Schedule)
Wide Dynamic Range	Yes
Digital Noise Reduction	3D DNR
Motion Detection	Off/On (8 Level)
White Balance	Auto/Manual
Electronic Shutter Speed	1/5 TO 1/20000s
On-Board Storage	Micro SD slot, up to 256GB
Alarm	N/A
Audio	Built-in microphone
Hardware Reset	Yes
Smart Feature	SMD(Human & Vehicle Detection(PD&VD)/Perimeter Intrusion Detection(PID)Line Crossing Detection(LCD)
Ethernet	RJ45 (10/100 BASE-T)
Video Compression Format	H.265/H.264
Max. Resolution Video Quality Adjustment	2MP (1920×1080) @25 fps 256Kbps — 4Mbps
Protocol	TCPIP, HTTP, DHCP, DNS, DDNS, RTP/RTSP, SMTP, NTP, UPNP, SNMP, HTTPS, FTP
Application Programming Interface	ONVIF
Operating Conditions	-35 to +55 C/ < 95% RH
Ingress Protection	IP67
Power	DC12V: max. 2.9W, PoE: max. 3.9W
Material	Plastics & Metal
